Club Meeting: 27 May 2015
Report by : Ian Connelly
Photos: Ross Johnson
In typical Terry fashion the demo started with a story about the history of the caddy spoon and how valuable tea was etc. etc. then he finished by saying what he read on the net was very interesting and we should all go and read it because he had forgotten and just made up everything. Terry had many different spoons to show, which ranged from functional to purely decorative.
Mount a 47 x 47 block, in a 50mm chuck with a steb centre in the tailstock
Round with the roughing gouge
Smooth with the skew
Mark out a ‘ball’ at the spoon end, using a parting tool to defined the sides and round roughly
Shape the handle
Terry used a sharpened pipe to tidy up the rounded ball (ideally the pipe diameter is less than the ball diameter ehh Terry)
Remove the tailstock, and clean up the end
DON’T PART OFF YET!
Take out of chuck and use bandsaw to split down the middle (the square end makes this easier)
Make a jam chuck to hollow the spoon, some people may find the hot melt is also required to help hold it.
Sand the spoon and handle.
Mount flat piece of wood between steb centres. (Terry used wood about 12 x 80mm)
Turn the handle
Part off at end of handle
Shape spoon with bandsaw, grinder, sander, dremel …… (hand tools probably work too, but Terry avoids these)
