A journey towards a multicentred, twisted plane, three sided vase based on the development by Barbara Dill. Andrew discussed the production passage and how things were achieved. Also, discussing the integration of trade apprenticeships and metal work and the development of production turning in engineering.
The overall aim was multi-centred bowls, twisted access of multiple sizes. In this demo, three sided goblet using this technique. Andrew’s long-term goal was to develop a method to make equal and exact multiples using an interesting and wide-ranging approach based on jigs, jams, and their application to fabrication of wooden lathe turned objects.
Andrew discussed the effect hours of design work for his movement into prop work and construction in TV film and theatre. The skill set devised in the making props for film production sets made a contribution towards his turning. Assisted by the subsequent movement through the NAW courses including training and colouring by Emma Rees Jones. Again further exacerbated by sides into carving and the techniques of working with Styrofoam. Also noting Has enjoyment of seeing it applied to the world of wood.
The project: A multicentred centred twisted format goblet based on the Barbara Dill premise. There is a project sheet available from www.sawg.org.nz: Triangular Vase. The sheet provides dimensions project outlines the starting point that to exercise on this style of vessel. There is an outline in the SAWG project section provided critical starting measurements. And, often as usual, importantly, the set of measurements that need to be organised and undertake the appropriate order for the establishment of centres-in this case sets of three.
Andrew stressed that the key is the setting out of the centrelines. The establishment of the axis turning points in the final shape are defined by the height and centre point diameters. The SAWG project sheet covers this quite clearly.
Interesting set of approaches was provided by the placement of the axis centre circle points to find the parameters and the ensuing shape. These measurement ratios and features provide rotation of the parallel sides in the movement of the curve to the next turning position. Each section is a repeat of the previous and with the precision of each section defining the size and form of the final piece.
The amount of twist is defined by the offset of the parallel sides and the planned shifting centre marked point. This demo Andrew three setpoints, hundred and 20° separate on a in a circle around 15 mm diameter. Still stuck on the measurements, try the SAWG project
Andrew stressed that this is not a major volume job. Fun can be had by changing the position of the axis centre points that will allow maintenance of angle and allow shape change. The working of these features into specialised jigs provides visual presence of the new shape. The setting of the jig curve provides a visual of the final shape. The construction the jigs is another item.
Standard process: Hollowing for the goblet was standard, a small spigot for the chuck, guide hole for the forstner bit. Many little tips turned up: A round ended drill bit was used to finish the base within the confines of the three sided, twisted, goblet.
Concern given to the direction of cutting. Andrew stresses that the direction of cutting is critical to the finished product. “Same cutting direction for each side.” And finally: “each little bit counts.”
Club Meeting: 3rd April 2024 Report by: Bob Yandell
The ‘More Jigs’ demonstration stems off the back of the demo which Jon did last year where he demonstrated a threading jig which he built. In tonight’s demo Jon demonstrates three more jigs which he designed and built to assist in his journey as a woodturner.
Having an engineering background the jigs were well thought through and constructed. Whilst some of the jigs will be beyond the skill set of members to replicate, the principles of each jig demonstrated are useful for the viewers.
Jon stated that he was in a predicament. He volunteered to do the demo last year as he had built some of the jigs. But all demo nights were full so he was given tonight’s date. He was unaware of the ‘Art Deco’ term theme until this year, and none of his tools or jigs are built in an art deco style. He apologised to the audience and said that unfortunately he will be keeping art deco to a minimum in this demo.
Spigot/tenon marking
Jon first highlights the issues (and limitations) of tenon marking using calipers, as taught in the Introductory Course. This includes the potential of the right hand leg touching/catching the spinning wood, which could pull the calipers out of your hand. That can be quite scary for new turners. Also, trying to mark a tenon when the tailstock is up is always challenging.
Jon then showed his homemade tenon marker. The jig was made from aluminum but it can be made from anything that is of hard material. This could be things like industrial formica or some hard timber such as a piece of kwila decking. There are two tenon markers on the jig, one for 50mm jaws and the other for 100mm jaws. Each marker has two pins, one sharpened to a point which engages with the centre of the work piece, and the other shaped like a vertical line which does the actual tenon marking. Jon used 2mm drill bits for the pins as these are high speed steel and they will last a long time.
He demonstrated the jig on a bowl painted by his daughter Nikita. To define the tenon on a bowl blank you must first mark the center of the base. This is achieved by either using the point of the skew or by bringing up the tailstock and making a dimple with the live centre. Jon then proceeds to mark tenons for 50mm and 100mm jaws on the workpiece But wait! That was a bit too easy. Any homemade jig could be used to easily mark a tenon when the tailstock is out of the way. But what happens if the tailstock is up and it cannot be removed, like when turning between centres? Well Jon has built-in a solution for that. Jon has strategically placed the 50mm pins in specific positions. The marking pin is a certain distance from the edge of the jig. Jon explains that the jig can be held flush on the side of the tailstock quill, and a spindle can be marked very easily with the tailstock engaged on the workpiece. He shows the process and the tenon marking is bang on size.
Lastly Jon shows a method of tenon marking which is by far the easiest and you don’t even have to build a jig. By simply shaping the point of a flat pencil (similar to what we have on our lathes), so that the lead is a little offset, the pencil can be used in the same way as the jig (held against the side of the tailstock quill), to mark a tenon. Again the size is measured and it is bang on.
Fluting jig
The starting point is the installation of a table on the bed of the lathe for the fluting jig to slide on. The table was 18mm MDF but similarity stable and flat material would work. Jon had secured a steel plate the width of the gap on the bed to which he had locking latches at each end. These are designed to be tightened from the top with countersunk bolts and no spanners or sockets are required to be held underneath.
Jon then installed an indexing system onto the lathe. The indexing system consists of an indexing plate and a selector arm. The indexing plate has a number of holes in concentric rings around the plate. Each ring of holes allows for numerous indexing configurations. There are over 1300 holes in the indexing plate, which took three days to make. Because of the flush headstock bearing design of the Nova lathe, he placed a 1mm washer between the indexing plate and the bearing on the headstock. This stops the indexing plate from binding on the bearing.
The chuck, 50mm, was then installed and tightened to lock the indexing plate in place. The demo wood was mounted and the power to the lathe was turned off, for safety reasons. The indexing selector arm was also installed.
The fluting jig was designed from the Paul Howard fluting jig. Jon designed and built a frame to support and allow vertical positioning of a trim router. The base is made from 10mm thick plate which minimises the jig from tipping. There is also a Polyethylene (PE) base underneath the steel plate to allow easy movement without resistanc
In the demo Jon showed two types of fluting processes. First he used a ½” cove router bit and cut flutes around the outside of a bowl. Because of the shape of the bowl, the flutes start deep on the top edge then fade out down the side of the bowl for a pleasing effect. The number of flutes was calculated by dividing the size of the router bit into the circumference of the bowl. This gives the number of flutes side by side, but in the demo
Jon indexed the workpiece so that the flutes were spaced out with a ½” gap between the flutes. There are many different combinations so it is up to the person doing the fluting to do what they want for their particular workpiece.
The depths of the flutes were controlled by mounting a fence to the table. Then Jon used thin metal rulers as spacers between the jig and the fence so that the full depth of the flutes can be cut in several passes by removing one ruler at a time. This reduces tear out and burning of the workpiece.
For the second type of fluting Jon removed the top part of the jig from the heavy base and fitted it to a hinge base that he built. The hinge base allows for arc cuts across the rim of a bowl. For this operation the jig is clamped in position parallel to the bed. Jon had pre-turned a sample workpiece where he cut 4mm grooves into the underside of a wide rimmed bowl. A 6mm straight router bit was installed into the router and
Jon demonstrated cutting arc style flutes in the top of the rim. This produces a lattice type effect. In the style of Dick Veitch magic, Jon pulled pre-turned finished samples of both the outside fluting and the lattice work out of a box so that they could be handed around. This demo showed two ways to flute with the jig, but if you use your imagination, there is so much more that can be done with the fluting jig.
Bowl from a board jig
Commonly referred to as a ‘band saw bowl’, making bowls from flat boards is a great way to use thin boards that you would otherwise not use. Rings are cut from the board and glued together into the shape of a bowl. This demo required a board that is flat. A waste block is attached to the center of the board and a tenon is cut into the waste block so it can be mounted into a chuck.
Jon has built a jig for cutting the rings from a flat board. Unlike a band saw bowl, the rings are cut out in one complete piece and there is no cut in the ring. There are three parts to the jig, the tool rest, the parting tool and the angle blocks. The tool rest fits into the banjo. It has been designed to hold the blade on the parting tool straight so that parting can be completed accurately at a specific angle. The parting tool was homemade from a thin parting blade from an engineers lathe. The angle blocks are used to set the desired angles when parting. There are five angles that can be used – 35, 40, 45, 55 and 60 degrees.
In this demo Jon used 40, 45 and 55 degrees for the cuts. A line is marked in from the edge of the board by the thickness of the board. So if the board is 18mm thick, the line is 18mm in from the edge. The parting tool is set to 40 degrees and the first ring is cut. It is important to not push the tool hard and to go slowly when you start to cut through to the other side. This reduces tear out. Once the ring is cut it detaches from the board and spins around on the chuck so you have to be quick on the stop button on the lathe. The ring cannot come off so the chuck is removed from the lathe to release the rin
To work out the position for the second cut the inside of the first ring is measured and then drawn onto the remaining of the board. This time the parting tool is set to 45 degrees and the second ring is cut. The same process is used to work out the position of the third cut. This time the parting tool is set to 55 degrees and the ring is cut.
There are four pieces in total, 3 rings and the rest of the board which is still mounted in the chuck. The rings are then stacked on top of each other to form a bowl shape. Because Jon used different angles, a natural “curve” of the bowl can be seen. This also provides more wood material for further shaping when the bowl is turned. The rings are glued together, and once dry, the final bow can be finish turned.
Jon showed some finished items and explains why he used the different angles. In layman’s terms he used CAD (cardboard aided design) on the white board to show how the different angles work with each other to provide the natural bowl shape. He also showed a CAD model where all of the rings are cut to 40 degrees. This results in a bowl with straight sides which looks a lot like something from the art deco era. With that Jon pulls another finished item from the box and says, “Ladies and gentlemen, a bowl from a board in the style of art deco”.
Most of Jon’s jigs including the threading jig can be seen on his YouTube channel. Go to YouTube and search for The Hobby Machinist NZ.
Club Meeting: 20 March 2024 Report by Graema Mackay
Trefor and Terry Scott discussed approaches to starting on, looking into and working river and beach rolled burls. The discussion had present a range of sizes, weights, densities, shapes, and variegated holes. The emphasis on individual view and making decisions on what the approach will be and the type of system.
An open discussion from opposing angles of viewing. There was a discussion movement away from the traditional multi-center bowl and moved to and opinion through to generation and development of art things, sculptures, and integration into other media.
The traditional: Keeping it natural. Using the surface. Keeping the surface as it is. Making a considered attempt to keep the shape. Different applications and holding techniques i.e., hot melt glue. Counterweights in traditional application.
Changes: Using balance to apply a different place/change to the piece. Working on the form of the piece. Frames and borders. Using the original shape/surface. Re-looking at the surface and what can be done with it.
A wider view: Looking at the history of the wood. Story of the piece and how it got there. Picking a piece to show the story. A new view and new center. Presenting another way.
Individual aspects: Open to options. Open to different cutting systems. Open to new applications/different applications. Improving skill sets.
Most importantly: working on a range of views and approaches, trying different ways, and sharing knowledge.
Club Meeting: 20 March 2024 Report by: Graeme Mackay
The Trefor choice was taking a safe approach and keeping the goal of “what is being made,” an initial secret. Well, as secret as one can make it.
There were several pieces under the magic blankets and covers. Start being to keep up interest and putting pieces and places to hide things. However, there was a very standard opening for a practical Lathe worked piece set between centers and made roughly round-using a Skew of course.
As always, the Teacher. Trevor noted that the object of the exercise was to promote tool techniques and ensure that “everything lined up.”
Rebates and coves started shaping things up as did the Jacobs chuck, changing structurally inner with a 40 MM hole in the center. A short tube turned to equal thickness was some cleaning up. Then some simple grinding work, and sanding to turn a small cup into a small salt spoon.
The practicality moved on to small Spatulas. Wood Sof course These units were produced using standard techniques, cuts, and correct techniques. Trefor mentioned to remember your teachings and start cutting from the tailstock rather than the drive end. Also, that pre-prep saved “a lot of energy” and kept a person on track. In this case the Demonstrator.
Again, simple straightforward way of holding a flat narrow piece on the chuck and, care taken choosing the correct. Then, shaping the shoulder and coving the handle, while not being to be too clever.
And, of course, ensuring that the handle is able to take the appropriate load of tailstock pressure being used in the preparation.
The oops highlighting this load carrying issue. Summarised in the phrase: thickness versus strength.
Forward in cheerfulness, standard traditional Woodturning and a very practical result.
Club Meeting: 8 March 2024 Report by: Graeme Mackay
Style developed in the 1920s appears in a wide range of forms with each country or region is putting forward their own version or direction. The style allows a full range of work and material. In this case, individual artists or institutions using wood or associated materials.
The individual contribution in this instance was based on using a series of wood or MDF jigs to make a vase in the style of Art Deco. A seemingly simple object the complex base formed on jigs.
As with many simple projects, there is an extensive amount of accurate and well measured preparation. The seven layers require a very distinct set of jigs plus guide for foot hold shaping jigs and alignment pegs.
The visual show layers are matching with differing diameters and differing jigs. A central core – again with a different diameter and its own shaping jigs form the base. Along with this central piece are two Dowel shaped feet (30 mm diameter) with their own construction method.
The shaping system is a series of specialist jigs that is centred on alignment pegs. These pegs appear in key positions making the alignment of the jig system relatively simple (?) and straightforward in application.
The Assembly: the accumulation of pieces produced through jigs is a straightforward come together and a standard gluing process using the alignment pegs. A process that the Demonstrator calls a common engineering process or in short; “simple”.
Tools: There is a small range of tools and materials that are required: Drill press, power drill, bandsaw large, spindle moulder, spindle sander, Brad point bits, Forstner bits, sanding blocks, lathe, Dowling production jaws, drum sander, trimming saw, undercoat, spray can, finishing paint. And timber for individual layers, base form, Dowling, jigs, sacrificial jig timbers, pegs, and bits.
A fun demonstration to watch: The individual layers and pieces coming together make an art deco style form when they emerge from the array of jigs and formers and come together in this simple vase form.
Club Meeting: 14 February 2024 Report by: Graeme Mackay
Editors note: I missed the meeting due to Covid-19, it appears there was also a lack of a photographer on the night so the header photo is the only one I have found (stolen from facebook)
Demonstration With Art Deco design style
A well-reasoned introduction about the place of his teacup and saucer. The works following the style of a previous demonstrator who provided the Teapot to start.
The base wood was avocado in two blocks of 130 x 100 x 100 mm. And sized to emphasise the straight lines of Art Deco design work. The Woodturning process was straightforward.
The block for this also was roughly cylindrical. As per Dick’s comments, spigots on the top start the process. Next to bottom spigot that allows the marking the size the teacup/author. Making sure that the foot was wide enough to fit the planned saucer of around 130 mm diameter.
Measuring: An important part of the process of ensuring that the wall thickness was even and sufficient to cover the straight sides of the Art Deco style saucer. On the finishing of spigots, Dick offered a variety of systems to take the base spigot off. These range from large diameter chucks through to standard Coles tools.
The cup was simple and following standard processes. The emphasis was on measurement and checking. The style was nothing fancy. The main choice being the use of, regular vertical grain.
Spigot at both ends of the cylinder, standard block, in this case, a square block 100 X 100 x-100 mm. millimetres. A reminder to check measurements and marking cut of the foot. The straight line from the lip edge to the foot has its own little issues centering around need to have even wall thickness.
The Cup Handle fixing raised interesting questions around which method to use. A good variety of options put forward; Dick taking the high-tech rotary pathway along with bits of holdings, brackets, and associated fixture devices.
All of which needed short period of adjustment and trial. The holding system in straight forward and glue fixed with minor adjustments. Actually, an extensive round of adjustments.
Dick put forward several challenges for painting, embellishing, and applying patterns. A number of quite interesting methods were used, discussed, forwarded, group reviewed with some traditional options. And a good use of stencils.
The group disorder indicated that there were many simple systems. All of which put forward with great crowd support.
Terry Scott showed a teapot in what he believed was the style Art Deco that is the term theme. Whether it was Art Nova as he believed it certainly was a product design that would be appreciated whatever category it might be in.
The wood, Macrocarpa, began as a 110x110x250(?) block and a piece 110x 20×250 flat. The latter was for the handle and spout.
The block was mounted between Steb Centres and turned round with the roughing gouge with the tool rest just above centre. A tip given by Terry was to mark the bevel with a black felt tip to see how the bevel was rubbing against the wood because the black should be removed from the cutting edge across the whole bevel and not just the tip/cutting edge.
Once round to 110mm, cutting from the centre to the end to avoid clipping off a splinter , which is a real possibility if you come in from an end, Terry cut a spigot on the tail stock end to fit the 100mm chuck. The following points were marked from the spigot- 20/150. Using the parting tool on the 20mm mark and cutting on the 150mm side a groove was cut to achieve a diameter of 80mm. Between the roughing gouge and skew a straight line was cut. Surface was finished with clean cuts by the skew moving slowly down the slope to the base of the teapot. The base was also cut as the access was cleared. Terry pointed out that the slower the movement with a sharp tool, ensured no spiralling.
The profile was then marked, in pencil, at each index of the chuck from the 150 to the 80 diameter. Lines were also marked every 10 – 20mm up the side. The resulting grid pattern was for determining the location of the spout and handle but can also be used for positioning graphics.
The base was then placed in the 100mm chuck, ensuring alignment using the centre created by the Steb centre in the now top, the chuck was tightened and tail stock removed.
Using a Forstner, in an extension, a hole was drilled to depth as marked with masking tape on the shaft, remembering to remove swarf/wood regularly and allowing the forstner to cool.
The top of the teapot was cleaned up and a recess for the lid to a depth of 5/10mm. The interior wood was removed by using a combination of hollowing tools.
The lid was made from cross grain wood and the process was as any lid with a knob.
The handle and spout were drawn onto the board and the angle of the handle was 85 not a right angle.
The spout and handle were shaped to fit the curve of the teapot. Panel pins were inserted, 2 on each interface between the surface of both spout and handle and then glued onto the teapot using the grid lines to ensure the correct position especially for the spout so outlet is below lid
Club Meeting: 22 November 2023 Report by: Kieran FitzGerald
John rescued us this week when he responded to a last minute request to fill in for a demonstrator who had to withdraw for urgent family reasons. We are indeed very grateful to John for his unreserved and willing acceptance to take on this role.
The demonstration showed us how to make a truly natty spinning top which is somewhat different to others I had previously seen. The trouble was I was sitting in the back rows, and the top was rather tiny. At the beginning of the demo I had no idea what the finished product was going to look like. So as I jotted down notes of what John was doing I was silently hoping like hell it all came together in the end. It did – I think.
The top is made up of 5 components. Part 1 – the tip. For this John used a brass rod (purchased from RS Components). I’m estimating the diameter of the rod at 4mm, and the final cut length of the tip about 15 – 16mm. He held the rod in a collet chuck and with it slowly spinning in the lathe he filed the sides down to about 2mm, and then cut it off to length. No need to work on the tip at this stage – that will be done later.
Put the rod aside. The second component to make is a tricky little ring, or yoke – call it what you will – I will refer to it as a ring. Because of its delicate nature, this should be made from a strong, tight grained wood. John is using black maire. With production techniques in mind, John prepares for this part with a view to making 4 or 5 rings from the one piece of wood. He takes a perfectly square 40 x 40 x approx 90mm blank, and marks it out for 6.5mm holes at 15mm centres. He drills the holes right through, as straight as possible. Then he cuts a tenon for his 35mm jaws and secures it in the chuck on the tenon. He rounds it down to about 30mm. Next he rolls beads along the length of the piece, with each 6.5mm hole at the high spot of each bead. He sands and finishes with wax, then drills the centre with a 19mm forstner bit. The first ring is then parted off – the finished width is around 12mm. John then uses a sanding disc on the lathe to create a small flat on each side so you can grasp it with your fingers. He sands the centre of the ring with a split dowel with a sandpaper wrap spinning in the lathe, and sands and waxes the entire ring. John recommends using a Beall system finish if you have one.
The next part to make is the main body of the top. The blank for this is about 55 x 55 x 60 long. The size is not critical, as long as the finished diameter is about 50mm. Nor is the final shape of the top set in concrete, although I would imagine for longer spin time a low centre of gravity is preferable. John turns the bottom end of the top first, to a broad conical shape, with a finished diameter of 50mm. He creates a small flat at the very bottom, and drills a hole to accept the brass tip in a tight, press fit. A long drill can wander off centre, so John uses a short, centreing drill bit. He taps the tip home with a hammer, and then by turning, filing and sanding, he brings it to a tidy point.
The critical feature of the top is to have the tip centred at the bottom, and the spindle (yet to be made) centred exactly at the top, so that the axis of the spinning top is vertically centred fair and true through the top. John has tried different methods to achieve this, but the most successful is to create a tiny spigot on the bottom of the body of the top while it is still mounted on its original tenon. Then it can be turned around and mounted in the jaws and will be exactly on centre. The spigot only needs to be about 1mm deep, but once mounted it needs to be turned with very gentle cuts. If the spigot is cut to the near closed diameter of the jaws, the grip is stronger and the claw marks of the jaws will be minimised to near invisibility. It helps to have a sharp face on the gripping end of the jaws (ie, no chamfer on the claws of the jaws, this can be achieved by carefully grinding them flat). (Note: it is amazing how securely a piece can be held by the tiniest of spigots, and this technique can be deployed in a variety of situations.) Having cut the spigot on the bottom, John advises that at this stage the bottom of the top may be coloured or textured. Turn away as much waste wood as you can at this stage while it is still firmly mounted. Sand and wax. Next, turn it around in the chuck and carefully turn the top portion of the body. John cuts the top to a rounded shape, being mindful of the need to keep most of the weight in the bottom portion of the top body. Once shaped, using a drill in the tailstock, drill a 6mm hole which will accept the shaft (to be made next).
Sidenote: It is worth observing that in the woodturning duo that is Annita and John, blue tape denotes the tool belongs to Annita, and yellow tape indicates John’s ownership. Learn from this.
Component number 4 is the spindle or shaft. This is a dowel held in pin jaws and cut down so that one end features a tight press fit into the body of the top (using the tailstock as a press), a spindle section which passes through the holes drilled in the ring, and a knob at the top to prevent the ring coming off. The shaft must be long enough to accommodate the section that fits into the body, the diameter of the ring plus a small clearance at each end, plus the knob. The ring must be allowed to spin freely on the spindle. At the point on the spindle which is at the centre of the ring, drill a small hole through which the string will be passed, and countersink to accommodate the knot in the string. Part it off, fit it all together and press it home.
The fifth and last component is the string. This does not need to be long – about 250mm is sufficient. Stiffen one end with superglue and pass it through the hole in the spindle. Secure it with a knot at the other end.
Wind the string round the spindle, a tug or two, and you’re away. She spins like a ballerina. Thanks John, that was great.
Club Meeting: 15 November 2023 Report by: Kieran FitzGerald
Usually we think of woodturning as a means of turning round objects – not our Brucie. In what he described as his last demo before moving to Dunedin, Bruce’s mission was to make and decorate a perfect cube on the lathe. It may be tricky to describe in words, but the accompanying photos will illustrate the novel and somewhat delicate piece that Bruce produces.
I’m not clear what the origin of this design is, but Bruce informed us that in the past it has been made in metal by fitters and turners as part of their apprenticeship. Colin Wise has also previously demonstrated this technique at the club.
Hard woods are preferred for this exercise to provide strength for the finished structure and to get a finish which requires minimal sanding. Bruce chose matai for his demonstration piece, and had two completed cubes in swamp rata and black walnut.
To start the project, Bruce cuts a 70mm cube with the drop saw, as accurately as possible. Next he uses a dead flat surface to sand one side of the cube to perfect flatness. The finished size of the cube will be 64mm square, and the whole process requires total accuracy. The accompanying plans show the cut dimensions required, and the templates Bruce uses to accurately measure the depth and width of his cuts.
The initial turning of the cube (ie, facing off to 64mm on all sides) is done on a faceplate, and Bruce emphasised the need for the face of the faceplate to be perfectly true. At first Bruce could not get faces on his cube at 90° to each other, and it was because his faceplate was not running true. He used a digital dial gauge to measure it to within 0.2mm.
The cube is positioned on centre with the sanded flat side against the faceplate, and held with the tailstock. Dabs of hot melt glue will hold it when the tailstock is removed. A few gentle passes with the gouge will bring the depth down to the required 64mm. The finishing passes obviously need to be done with the tailstock out of the way. Use a steeledge ruler to make sure the side is perfectly flat. Give it a quick sand. Getting a straight and true face requires a very steady hand with the gouge. Bruce showed us how he points his index finger along the shaft of the tool, and supports the handle under his arm, so in effect the gouge becomes an extension of his arm.
Re-position the cube on the faceplate to the opposite face and repeat the squaring off process. Continue this until all six faces of the cube are down to 64mm and are perfectly square to each other. Use a set square to check for right angles – it may be necessary to use a paper shim to correct for any slight out of trueness. Mark the centre on each face as you go, for later re-positioning in the chuck. Make sure you carefully clean any residual glue off the faceplate so the face remains true. (Note that Bruce thought the project might take about 2 ½ hours from go to whoa, so to fit the demo into the shorter time slot he had already prepared five faces of the cube.)
I should mention that before any turning starts, an acruline alignment tool should be used to ensure the tailstock and headstock are perfectly aligned.
Now the fun begins – Bruce is ready to start tunnelling out the first side – this involves a series of perfectly centred concentric circles cut towards the centre of the cube. Bruce mounts the cube in a chuck which has two 100mm powergrip jaws fitted (numbers 1 and 4). He uses packers to protect the jaws from crushing the cube. He brings the tailstock up before fully tightening it down so he can centre it on his previously made centre mark. The first cut needs to be 54mm wide and 9mm deep. He scribes the position of the cut with dividers, and carefully makes the cut using a ½” skew and a small parting tool. The edge of the cut needs to be straight and the bottom flat. Bruce uses a template to achieve this. To get a clean cut the lathe speed is set at 2000rpm and the tools are super sharp. The next circle is cut at 40mm and 7mm deep, using exactly the same method. The third and last cut is 26mm wide and 5mm deep. Bruce then uses a 12mm brad point drill to drill a hole which passes through the centre of the cube, but not all the way through. He depth marked the drill bit at 40mm. When each side has been drilled the resulting hole forms the final hole within a square in the centre of the tunnelled cube.
The tunnelling process needs to be completed on each of the 6 sides of the cube. The second side is the side which is a 90° turn to the left or right, not the side directly opposite the first. Needless to say, as each side is tunnelled out and more wood is removed from the cube, the resulting structure becomes more and more flimsy. To strengthen the structure while he tunnels out the last side, Bruce glues a 12mm dowel through the centre of the cube, and secures this at each end with round plates inserted into the first circles cut on two opposing sides. This is removed at the very end when the last side has been tunnelled.
As he usually does, Bruce finished his demo with a random number draw using door numbers, and the giveaways were a tunnelled cube and sets of golden rule and sphere calipers. The lucky and grateful winner of the cube was none other than Dick Veitch, and other winners were Terry Bennett, Terry Scott, Ross Johnson and Lindsay Amies.
Thank you Bruce. This was indeed a challenging demo requiring precision and care, and delivered with all the banter and fun that we have come to expect. We are going to miss you; our loss is Dunedin’s gain.
Click on Plan below to load full size PDF for printing
Club Meeting: 8 November 2023 Report by: Roger Pye
This was a demonstration of intrigue and interesting variations to straight forward woodturning.
Our demonstrator was Peter Williams, a visitor from Northland Woodturners & Woodworkers Club. Whangarei. Peter, actually lives in Kerikeri, so twice every month, he makes the one and a quarter hour perilous journey from Kerikeri to Whangarei and back. That’s dedication to the cause.
There must be something about Kerikeri because it was only a few years ago that the manufacturer of “magic” Munroe hollowing tools moved to Kerikeri from the South Island.
Peter is also well known as the maker of Kareem Polishing wax. As a preliminary Peter had a short video on screen to show how his brother, who has always lived in England, has devoted his life to pottery. His point was that not all potters have to make round things on a potter’s wheel, as shown in the video. This being the case then “Why should he make everything round on a woodturning lathe”. So that turned out to be the subject of the nights demo.
Some examples of various finished items were displayed, all elliptical, although some had round bases to stand on. One was hollowed and carved to show feathers with see-through holes and cervices. Another was close to a live Tuatua seashell. The main point being that the elliptical shape can be turned provided that a wedge is used inside two slabs of matching wood. The accompanying photographs will show exactly the aim of this exercise.
Starting with an even grained piece of timber measuring about 125 x 125 mm and 250 long it is important to cut it exactly down the centre. Next a wedge is made from any suitable wood. This wedge will sit between the divided original slab. The wedge thickness at the blunt end will vary according to your choice of elliptical finished shape. (Your answer will be simple when you have made at least one) Anyway the true wedge shape is important. Best you make a cutting table for your bandsaw. (see photograph) The trick is to make a wooden slide to fit the running grove in your bandsaw table. Attach this to a sliding flat top which will be grooved for the travel of the bandsaw blade about ¾ of the way across. A back fence will be attached at right angles. Use a tapered sledge up against a side fence mounted on the sliding platform. Cut your wedge and clean the faces on a good flat sanding table.
Glue the wedge in place using papered joints. It is first necessary to put spurs in place to stop the wedge sliding out under clamp pressure. This can be a small dowel in the wedge thick-end area to be cut off at the tail-stock end later. Leave joints at least 24 hrs of even 48 hrs if possible, for glue to harden.
Turn the now tapered slab to a round tube, then start a selected shaped curve down to a small diameter of about 25mm at the tail-stock. Use a low speed as paper joints can be lethal. Create a chuck spigot for an 80mm chuck at the head stock end and cut off the small tail stock waste with handheld cross-cut saw. Remove and remount using a four-jaw chuck.
A 15mm Forstner bit will be used to start the hollowing process when drilled to the full depth of the planned interior. Next drill several 9mm holes through the wedge section into the centre. This makes it possible to gauge the thickness while hollowing. It also makes it easy to blow out shavings with an airgun.
It is also advisable to choose a solid ring of a suitable diameter to glue in place over the shaped exterior some halfway along the hollowed-out zone. But first apply masking tape over the gluing area to avoid nasty stains occurring. Also run a knotted cord against the ring to provide easier removal. Glue on the ring with Hot Melt Glue.
When hollowing is finished, remove the ring and unmount the workpiece from the chuck then open the two paper joints with a long carving knife. Sand on a flat sanding board to remove unwanted paper and glue.
Take special care to glue both halves together using the lathe chuck at one end and soft jaws fitted with heavy sponge at the other. A “glue-chuck”(see illustration) is used with the correct ring to hold the work in place for the removal or shaping of the base spigot.
